EM500 Open-Loop Vector Control Inverter User Manual
133
F17
Virtual I/O Function Group
F17.00
VX1 Virtual Input
Function
Same as numeric input terminal
function of F02 group
0
〇
F17.01
VX2 Virtual Input
Function
0
〇
F17.02
VX3 Virtual Input
Function
0
〇
F17.03
VX4 Virtual Input
Function
0
〇
F17.04
VX5 Virtual Input
Function
0
〇
F17.05
VX6 Virtual Input
Function
0
〇
F17.06
VX7 Virtual Input
Function
0
〇
F17.07
VX8 Virtual Input
Function
0
〇
F17.08
Positive/Negative
Logic of Virtual
Input
D7
D6
D5
D4
D3
D2
D1
D0
000
00000
〇
VX8
VX7
VX6
VX5
VX4
VX3
VX2
VX1
0: Positive Logic, Enabled at
On/Disabled at Off
1: Negative Logic, Disabled at
On/Enabled at Off
F17.09
VX1 - VX8 Status
Setting
D7
D6
D5
D4
D3
D2
D1
D0
000
00000
〇
VX8
VX7
VX6
VX5
VX4
VX3
VX2
VX1
0: VXn Is Same as VYn Output
1: Status to be Set by F17.10
F17.10
VX1 - VX8 Status
Setting
D7
D6
D5
D4
D3
D2
D1
D0
000
00000
●
VX8
VX7
VX6
VX5
VX4
VX3
VX2
VX1
0: Disabled
1: Enabled
F17.11
VX1 Effective
Delay Time
0.000 - 30.000
s
0.000
●
F17.12
VX1 Ineffective
Delay Time
0.000 - 30.000
s
0.000
●
F17.13
VX2 Effective
Delay Time
0.000 - 30.000
s
0.000
●
F17.14
VX2 Ineffective
Delay Time
0.000 - 30.000
s
0.000
●
F17.15
VX3 Effective
0.000 - 30.000
s
0.000
●
