EM500 Open-Loop Vector Control Inverter User Manual
15
EM500-400G/450P-3
400/450
725/810
EM500-450G/500P-3
450/500
820/900
EM500-500G/560P-3
500/560
900/1010
EM500-560G/630P-3
560/630
1010/1140
3-phase,
220～230V
EM500-0R7G/1R5P-2B
0.75/1.5
4.8/8.0
EM500-1R5G/2R2P-2B
1.5/2.2
8.0/10.0
EM500-2R2G/3R0P-2B
2.2/3.0
10.0/13.0
Single-phase
220～230V
EM500-0R7G/1R5P-1B
0.75/1.5
4.8/8.0
EM500-1R5G/2R2P-1B
1.5/2.2
8.0/10.0
EM500-2R2G/3R0P-1B
2.2/3.0
10.0/13.0
★
the difference between inverter and motor shall not be more than two power ratings.
Please try to select a motor that matches with inverter in rated current.
EM500 technical specifications are shown in Table 1–2.
Table 1-2 EM500 Technical Specifications
Items
Specifications
Input
Rate Voltage
Range
3-phase 380V-20% - 415V+20%, 3-phase or single-phase 220
– 230VAC; 50 - 60 Hz±5%, voltage unbalance <3%
Output
Maximum
Output Voltage
Maximum output voltage is identical to input voltage.
Rated Output
Current
100% non-stop rated current output
Maximum
Overload
Current
Model G: 150% rated current for 60s, 180% rated current for
10s and 200% rated current for 2s
Model P: 120% rated current for 60s, 150% rated current for
10s and 180% rated current for 2s
Basic
Control
Functions
Control Mode
V/F(VVF) and SVC
Input Mode
Frequency (speed) input and torque input
Start/Stop
Control Mode
Keypad, control terminals (2-wire sequence, 3-wire
sequence) and communication
Frequency
Control Range
0.00 - 600.00 Hz /0.0 – 3000Hz
Input Frequency
Resolution
Numeric input: 0.01 Hz/ 0.1Hz, analog input: 0.1% of
maximum frequency
Governor
Deflection
1: 50 (
VVF
),
1:200
(SVC)
Speed Control
Accuracy
±0.2% rated synchronous speed
Acceleration/De
celeration Time
0.01-600.00 seconds/0.1 - 6000.0 seconds/1 - 60000 seconds
V/F Features
Rated output voltage: 20% - 100% adjustable; frequency
base: 1 Hz - 600 Hz/3000Hz adjustable
