Sinee EM500 - Output Terminal Function Group

EM500 Open-Loop Vector Control Inverter User Manual
90
Maximum Input of
Curve 3
F02.49
Minimum Input of
Curve 4
-10.00 - F02.51
V
-9.90
●
F02.50
Setting
Corresponding to
Minimum Input of
Curve 4
–100.0 - +100.0
%
-100.0
●
F02.51
Input of Inflexion 1
of Curve 4
F02.49 - F02.53
V
-5.00
●
F02.52
Setting
Corresponding to
Input of Inflexion 1
of Curve 4
–100.0 - +100.0
%
-50.0
●
F02.53
Input of Inflexion 2
of Curve 4
F02.51 - F02.55
V
5.00
●
F02.54
Setting
Corresponding to
Input of Inflexion 2
of Curve 4
–100.0 - +100.0
%
50.0
●
F02.55
Maximum Input of
Curve 4
F02.53 - 10.00
V
9.90
●
F02.56
Setting
Corresponding to
Maximum Input of
Curve 4
–100.0 - +100.0
%
100.0
●
F02.57
AI1 Filter Time
0.00 - 10.00
s
0.10
●
F02.58
AI2 Filter Time
0.00 - 10.00
s
0.10
●
F02.59
AI3 Filter Time
0.00 - 10.00
s
0.10
●
F02.60
AI4 Filter Time
(Expansion Card)
0.00 - 10.00
s
0.10
●
F02.61
AD Sampling
Hysteresis
2 - 50
2
〇
F03
Output Terminal Function Group
F03.00
Y1 Output Function
0: No Output
1: Inverter Running (RUN)
2: Frequency Reach Range (FAR)
3: Output Frequency Detection Range
FDT1
4: Output Frequency Detection Range
1
○
F03.01
Y2 Output Function
3
○
F03.02
R1 Output Function
(EA-EB-EC)
7
○
F03.03
R2 Output Function
(RA-RB-RC)
8
○
