EM500 Open-Loop Vector Control Inverter User Manual
180
X1 Numeric Input Function
See Table 7–4
Functions of
Numeric
Multi-Function
Input Terminals
X2 Numeric Input Function
X3 Numeric Input Function
X4 Numeric Input Function
X5 Numeric Input Function
X6 Numeric Input Function
X7 Numeric Input Function
AI1 Numeric Input Function
AI2 Numeric Input Function
AI3 Numeric Input Function
AI4 Numeric Input Function
(Expansion Card)
X8 Numeric Input Function
(Expansion Card)
X9 Numeric Input Function
(Expansion Card)
X10 Numeric Input Function
(Expansion Card)
X11Numeric Input Function
(Expansion Card)
X1 - X11 and AI1 - AI4 are 15 numeric multi-function input terminals. By setting
the function codes F02.00 - F02.14, user can define the functions of those input terminals
respectively.
For example, if F02.00=1, X1 is “RUN”. If the terminal control (F00.02=1) is
selected as the command source, then inverter starts the function RUN when X1 terminal
input is valid. See Table 7–4 for specific function options.
If more than one terminal is set to the same function (except the function 34), the
function is determined by the state of two terminals or logic. For example, If F02.00=1
and F02.05=1 ether X1 or X6 is effective “RUN” of inverter is effective.
Table 7–4 Numeric Multi-Function Input Terminals
Set “0: No Function” for an unused or fault terminal to prevent
false output.
If the terminal control (F00.02=1) is selected as the command
