EM500 Open-Loop Vector Control Inverter User Manual
231
motor temperature is greater than motor overheating alarm threshold (F07.05), the
numeric output terminal “25: Motor Overload Pre-alarming” is enabled and this signal is
used for instruction; if motor temperature is greater than motor overheating protection
threshold (F07.04), inverter will give an alarm about motor overheating fault (E12) and
start corresponding protection action.
★ Motor overheating fault (E12) can not be reset immediately until motor temperature
drops to a value far below the protection threshold.
No.
Function
Range
Unit
Default
Type
F07.06
Bus Voltage
Control Options
0: Disabled
1: Undervoltage Stall,
Enabled
2: Overvoltage Stall,
Enabled
3: Overvoltage Stall and
Undervoltage Stall,
Enabled
2
〇
F07.07
Overvoltage Stall
Control Voltage
110.0 - 150.0
(380V,100.0=537V)
%
131.0
(703V)
〇
F07.08
Undervoltage
Stall Control
Voltage
60.0 - Judgment Voltage at
Power Failure Ending
(100.0= Standard Bus
Voltage)
76.0
〇
F07.06=0: Disabled
Overvoltage stall disabled; it’s not recommended to set F07.06 as 0, if there is no
external braking unit.
Undervoltage stall disabled;
F07.06=1: Undervoltage Stall, Enabled
When bus voltage is lower than the value set through F07.08, inverter stops after
decelerating to zero, and gives an alarm for stable undervoltage fault (SIU).
F07.06=2: Overvoltage Stall, Enabled
f overvoltage stall is enabled, the stall voltage is set by F07.07.
DC bus overvoltage is generally caused by deceleration, because at the time of
