set value is, the better the energy saving effect will be. If it is set as 0.00, the energy
saving is disabled.
When the energy saving running is enabled, the energy saving conditions are
reached and the energy saving actuation time (F05.17) is maintained, then the energy
saving control will start.
These are optimized parameters for VF control of the synchronous motor. Generally,
user adopts the defaults
7.7 F06 Group: Vector Control Parameter
No.
Function
Range
Unit
Default
Type
F06.00
Speed Proportional
Gain ASR_P1
0.00 - 100.00
12.00
●
F06.01
Speed Integral Time
Constant ASR_T1
0.000 - 30.000 0.000: No
Integral
s
0.200
●
F06.02
Speed Proportional
Gain ASR_P2
0.00 - 100.00
8.00
●
F06.03
Speed Integral Time
Constant ASR_T2
0.000 - 30.000 0.000: No
Integral
s
0.300
●
F06.04
Switching Frequency
1
0.00 - Switching Frequency 2
Hz
5.00
●
F06.05
Switching Frequency
2
Switching Frequency 1 -
Maximum Frequency F00.16
Hz
10.00
●
Under the vector control mode, inverter adjusts the speed dynamic response of the
vector control by adjusting the PI regulator’s speed proportional gain (ASR_P) and speed
integral time (ASR_T). Either increasing ASR_P or reducing ASR_T would quicken the
speed loop's dynamic response. However, if ASR_P is excessive or ASR_T is insufficient
No.
Function
Range
Unit
Default
Type
F05.18
Compensation Gain of
Magnetic Flux of
Synchronous Motor
0.00 - 500.00
%
100.00
●
F05.19
Filter Time Constant of
Magnetic Flux
Compensation of
Synchronous Motor
0.00 - 10.00
s
0.50
●
