EM500 Open-Loop Vector Control Inverter User Manual
110
PID Setting Feedback Range)
F09.29
Sleep Delay Time
0.0 - 6500.0
s
0.0
●
F09.30
Awakening Action
Point
0.00 - 100.00 (100.00 corresponds to
PID Setting Feedback Range)
%
0.00
●
F09.31
Awakening Delay
Time
0.0 - 6500.0
s
0.0
●
F09.32
Preset PID Setting 1
0.0 – PID Setting Feedback Range
F09.03
0.0
●
F09.33
Preset PID Setting 2
0.0 – PID Setting Feedback Range
F09.03
0.0
●
F09.34
Preset PID Setting 3
0.0 – PID Setting Feedback Range
F09.03
0.0
●
F09.35
The Feedback
Voltage Upper Limit
The feedback voltage lower limit~10.00
V
10.00
●
F09.36
The Feedback
Voltage Lower Limit
0.00~ The Feedback Voltage Upper
Limit
V
0.00
●
F09.37
PID Integral Action
Choice in time of
change
0: Always calculate integral item
1: Start calculating Integral item
When the time set in F09.21has arrived
2: Start calculating integral item when
the error is less than F09.38
0
●
F09.38
PID Integral Action
G
iven
C
hange
T
time
Input
D
eviation
0.00-100.00
%
30.00
●
F10
Communication Function Group
F10.00
Inverter Address
1 - 247, 0 as broadcasting address
1
〇
F10.01
Modbus
Communication Bit
Rate
0: 4800
1: 9600
2: 19200
3: 38400
4: 57600
5: 115200
1
〇
F10.02
Modbus Data
Format
0: 1-8-N-1 (1 start bit + 8 data bits +1
stop bit)
1: 1-8-E-1 (1 start bit + 8 data bits + 1
even parity + 1 stop bit)
2: 1-8-O-1 (1 start bit + 8 data bits + 1
odd parity + 1 stop bit)
3: 1-8-N-2 (1 start bit + 8 data bits +2
0
〇
