Sinee EM500 - 7.15 F14 GROUP: MOTOR 2 PARAMETER

EM500 Open-Loop Vector Control Inverter User Manual
284
7.15 F14 Group: Motor 2 Parameter
EM500 inverter can be switched between two motors. User may perform motor
nameplate parameter settings, motor parameter tuning, the selection of VF control or
vector control, related parameters of the encoder, and parameters related to VF control or
vector control performance for these two motors respectively.
Motor parameters of the second group are listed in F14, with the function codes
having the same meanings as that of the first group.F14.00 - F14.34 correspond to F01.00
- F01.34 and they are respectively motor nameplate parameter, motor parameter, encoder
parameter, etc.; F14.35 corresponds to F00.01, for motor control mode; F14.36 - F14.76
corresponds to F06.00 - F06.40, as vector control parameters; F14.77 refers to the
acceleration/deceleration options for motor 2. In the following, only F14.72 is described.
For the other parameters, please refer to the descriptions of relevant parameter of Motor
1.
F14.77=0，the acceleration/deceleration time of motor 2 is the same as that of motor
1. Refer to descriptions of F15.03 - F15.09
F14.72=1/2/3/4, the acceleration/deceleration time of motor 2 is fixed as the
acceleration/deceleration time 1, 2, 3 and 4, which correspond to F00.14 - F00.15/F15.03
- F15.04/F15.05 - F15.06/F15.07 - F15.08 respectively
No.
Function
Range
Unit
Default
Type
F14.77
Motor 2
Acceleration/Deceleration
Time
0: Same as Motor 1
1: Acceleration/Deceleration
Time 1
2: Acceleration/Deceleration
Time 2
3: Acceleration/Deceleration
Time 3
4: Acceleration/Deceleration
Time 4
0
〇
