time is reached.
★ If the function code is set as 0.000s, the delay function will be disabled.
No.
Function
Range
Unit
Default
Type
F03.17
Y1 Output
Monopulse Time
0.001 - 30.000
s
0.250
●
F03.18
Y2 Output
Monopulse Time
0.001 - 30.000
s
0.250
●
F03.19
R1 Output Monopulse
Time
0.001 - 30.000
s
0.250
●
F03.20
R2 Output Monopulse
Time
0.001 - 30.000
s
0.250
●
When the output type of a function output terminal is monopulse output (see F03.05),
user may control the active level pulse width by setting monopulse output time to meet
various process or control requirements. See Figure 7-14 and Figure 7-16 for details.
No.
Function
Range
Unit
Default
Type
F03.21
Analog Output M1
See Table 7–7
Multi-Function Analog
Output Terminals
0
〇
F03.22
Analog Output M2
2
〇
F03.23
Y2 High-Frequency
Pulse Output
Function
11
〇
M1 and M2 are 2 multi-function analog output terminals and Y2 can be set as a
high-speed pulse output terminal (F03.07=1). By setting the function codes F03.21 -
F03.23, user may define the functions of output terminals.
For example, if F03.21=0, the function of M1 terminal is to output “Running
frequency (absolute value)”, and reflects present value of “Running frequency” (absolute
value)” by outputting different voltage values. If the running frequency increases from
0.00 Hz to 50.00 Hz (assuming F00.16=50.00), then the default condition is that the M1
output voltage increases from 0.00V to 10.00 V, with the same variation trend as that of
the running frequency. Specific functions available are shown in Table 7-7.
Table 7–7 Multi-Function Analog Output Terminals
Value
Function
Description
0
Running frequency
(absolute value)
0.00 Hz - Fmax, corresponding output 0.0% - 100.0%
