EM500 Open-Loop Vector Control Inverter User Manual
96
F04.27
Terminal Start
Command
Reconfirmation
0: Not to Confirm
1: Confirm
0
F04.28
Not Used
F04.29
Zero speed
frequency
0.00 5.00
Hz
0.25
F04.30
Initial Position
Search after
Power-on or Fault
0: Disabled
1: Enabled
0
F05
V/F Control Parameter Group
F05.00
V/F Curve Setting
0: Straight Line V/F
1: Multi-Dot Polyline V/F
2: VF to the 1.3rd
3: VF to the 1.7th
4: Square V/F
5: VF Complete Split Mode (Ud=0,
Uq=K*t=Split Voltage Source Voltage)
6: VF Half-Split Mode (Ud=0,
Uq=K*t=F/Fe*2*Split voltage source
voltage)
0
F05.01
Multipoint VF
Frequency Point F1
0.00 - F05.03
Hz
0.50
F05.02
Multipoint VF
Voltage Point V1
0.0 - 100.0 (100.0= Motor Rated
Voltage)
%
1.0
F05.03
Multipoint VF
Frequency Point F2
F05.01 - F05.05
Hz
2.00
F05.04
Multipoint VF
Voltage Point V2
0.0 - 100.0
%
4.0
F05.05
Multipoint VF
Frequency Point F3
F05.03 - Motor Rated Frequency
(Reference Frequency)
Hz
5.00
F05.06
Multipoint VF
Voltage Point V3
0.0 - 100.0
%
10.0
F05.07
Voltage Source of
VF Separation
Mode
0: Numeric Setting of VF Separation
Voltage
1: AI1
2: AI2
3: AI3
4: High-Frequency Pulse (X7)
5: PID
0
