Sinee EM500 - Input Terminal Function Group

EM500 Open-Loop Vector Control Inverter User Manual
84
F01.34
Motor Parameter
Autotuning
0: No Autotuning
1: Stationary Autotuning of Induction
Motor
2: Rotational Autotuning of Induction
Motor
11: Stationary Autotuning of
Synchronous Motor
12: Rotational Autotuning of
Synchronous Motor
0
〇
F02
Input Terminal Function Group
F02.00
X1 Numeric Input
Function
0: No Function
1: Run Terminal “RUN”
2: Direction R/F
3: 3-Wire Sequence Stop Control
4: Forward JOG (FJOG)
5: Reverse JOG (RJOG)
6: Terminal UP
7: Terminal DOWN
8: Clear UP/Down Offset
9: Coast to Stop
10: Fault Reset
11: Preset Speed Terminal 1
12: Preset Speed Terminal 2
13: Preset Speed Terminal 3
14: Preset Speed Terminal 4
15: Preset PID Terminal 1
16: Preset PID Terminal 2
17: Preset Torque Terminal 1
18: Preset Torque Terminal 2
19: Acceleration/Deceleration Time
Terminal 1
20: Acceleration/Deceleration Time
Terminal 2
21: Acceleration/Deceleration Time
Terminal Disabled
22: Operation Pause
23: External Fault Input
24: Switch Run Command to Keypad
1
〇
F02.01
X2 Numeric Input
Function
2
〇
F02.02
X3 Numeric Input
Function
11
〇
F02.03
X4 Numeric Input
Function
12
〇
F02.04
X5 Numeric Input
Function
13
〇
F02.05
X6 Numeric Input
Function
14
〇
F02.06
X7 Numeric Input
Function
10
〇
F02.07
AI1 Numeric Input
Function
0
〇
F02.08
AI2 Numeric Input
Function
0
〇
F02.09
AI3 Numeric Input
Function
0
〇
F02.10
AI4 Numeric Input
Function (Expansion
Card)
0
〇
F02.11
X8 Numeric Input
Function (Expansion
Card)
0
〇
F02.12
X9 Numeric Input
Function (Expansion
0
〇
