EM500 Open-Loop Vector Control Inverter User Manual
310
F17.38
Virtual Output
Terminal Status
VY8
VY7
VY6
VY5
VY4
VY3
VY2
VY1
000
00000
×
0: Disabled
1: Enabled
These function codes are used to display present virtual terminal status in real time.
7.19 F18 Group: Monitoring Parameter
This group of parameters can be used for viewing present status of inverter, but
cannot be used to operate them.
No.
Function
Range
Unit
F18.00
Output Frequency
Display present output frequency. Range: 0.00 -
Upper Limit Frequency
★
This parameter will be updated in real time only
when inverter is in speed control mode.
Hz
F18.01
Set Frequency
Display present set frequency. Range: 0.00 -
Maximum Frequency F00.16
★
This parameter will be updated in real time only
when inverter is in speed control mode.
Hz
F18.02
Not Used
F18.03
Estimated
Feedback
Frequency
Used to display estimated feedback frequency when
inverter is in SVC control mode. Range: 0.00 - Upper
Limit Frequency
★ This parameter will be updated in real time only
when inverter is in SVC control mode.
Hz
F18.04
Output Torque
Display present output torque of inverter. Range:
-200.0 - 200.0.
%
F18.05
Torque Setting
Display present set torque of inverter. Range: -200.0
- 200.0.
★ This parameter will be updated in real time only
when inverter is under torque control mode.
%
F18.06
Output Current
Display present output current of inverter. According
to motor rated power ratings:
0.00 - 650.00 (Motor Rated Power ≤ 75kW)
0.0 - 6500.0 (Motor Rated Power >75kW)
A
F18.07
Output Current
Percentage
Display present output current in the form of
percentage (relative to inverter rated current). Range:
0.0 - 300.0.
%
F18.08
Output Voltage
Display present output voltage. Range: 0.0 - 690.0.
V
