Sinee EM500 - Upper Mounting Hole; Base and Top Cover of Inverter (450 - 560 Kw); Installation of Base and Top Cover of Inverter (450

To Next Page

To Previous Page

EM500 Open-Loop Vector Control Inverter User Manual

388

If required, please inform while ordering and complete installation by yourself. See

Figure 11-6 for details.

Figure 11-5 Base and Top Cover of Inverter (450 - 560kW)

Figure 11-6 Installation of Base and Top Cover of Inverter (450 - 560kW)

11.6 Upper Mounting Hole

EM500 large-power inverter (450 - 560kW) can be accompanied with upper

mounting hole to make the machine stand against wall with machine back. If required,

please inform while ordering and complete installation by yourself. See Figure 11-7 for

details.

To replace base, you only need to

remove 15 M6*14 bolts on both

sides and on the back

To install top cover, only need to

tighten up 9 M5*12 screws on both

sides and on the back.

Base (Optional)

Top cover (Optional)
