Sinee EM500 - Auxiliary Function Group

EM500 Open-Loop Vector Control Inverter User Manual
128
F14.80
Motor 2 V/F Curve
Setting
0: Straight Line V/F
1: Multi-Dot Polyline V/F
0
●
F14.81
Motor 2 Multipoint
VF Frequency Point
F1
0.00
～
F14.83
Hz
0.50
●
F14.82
Motor 2 Multipoint
VF Voltage Point F1
0.0～100.0（100.0 = rated voltage）
%
1.0
●
F14.83
Motor 2 Multipoint
VF Frequency Point
F2
F14.81～F14.85
Hz
2.00
●
F14.84
Motor 2 Multipoint
VF Voltage Point F2
0.0
～
100.0
%
4.0
●
F14.85
Motor 2 Multipoint
VF Frequency Point
F3
F14.83～motor rated frequency
（
reference frequency
）
Hz
5.00
●
F14.86
Motor 2 Multipoint
VF Voltage Point F3
0.0～100.0
%
10.0
●
F14.87
Stop Mode
0: Ramp-To-Stop
1: Coast-to-Stop
0
●
F15
Auxiliary Function Group
F15.00
JOG Frequency
0.00 - Maximum Frequency F00.16
Hz
5.00
●
F15.01
JOG Acceleration
Time
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
5.00
●
F15.02
JOG Deceleration
Time
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
5.00
●
F15.03
Acceleration Time 2
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.04
Deceleration Time 2
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.05
Acceleration Time 3
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.06
Deceleration Time 3
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
