The input terminal function “42: Process PID Integral Pause” can be used together for
remote control. If the function code setting is disabled (F09.20=100.00), the input
terminal function does not work. See Table 7-14 for details
Table 7-14 Integral Separation Function Description
Mode
Description
F09.20
DI (42)
F09.20: PID Integral Separation Threshold；DI (42):
Process PID Integral Pause
100.00%
--
The integral (I) is always enabled
0.00%
-
99.99%
Up to the relationship between |e (k)| and F09.20, and the
status of DI
Disabled
If |e (k)| >F09.20, the integral separation will be enabled
Enabled
Integral Separation Enabled
No.
Function
Range
Unit
Default
Type
F09.21
PID Setting Variation
Time
0.000 - 30.000
s
0.000
●
PID setting variation time refers to the time required for the change from 0.0% to
100.0%. It is similar to an acceleration/deceleration function.If PID setting changes, the
actual setting value of PID will have a linear change to reduce the impact incurred upon
the system. After the initial value is set, the smooth setting will be invalid.
Function
Code
Name of Function
Code
Parameter Description
Unit
Default
Property
F09.22
PID Feedback Filter
Time
0.000 - 30.000
s
0.000
●
F09.23
PID Output Filter
Time
0.000 - 30.000
s
0.000
●
F09.22 is used for filtering of PID feedback. The filtering action is in favour of
reducing the interference impact upon the feedback, but causes the response performance
of the closed loop system of the process to go down.
F09.23 is used to filter PID output. The filter can reduce the possibility of sudden
change of inverter output frequency, but this can also reduce the response performance of
process closed loop system.
