13.2.2.4
Diagnostic function code
（0x700）
The function code is used to check whether the communication between the master and
the slave is normal. The host sends any 2-byte contents. The normal status response
packet is the slave address + exception code, and the contents are copied.
 request message
CAN-ID
0x700+slave address
DLC（Date Length）
2
Data Field
2 Bytes
 Response message
CAN-ID
0x700+ Host address
DLC
（
Date Length
）
2
Data Field
Slave address+ Abnormal code(00)

Error message
CAN-ID
0x780+ Host address
DLC
（
Date Length
）
2
Data Field
Slave address+ Abnormal code
