EM500 Open-Loop Vector Control Inverter User Manual
247
3: AI3
4: AI4 (Expansion Card)
5: High-Frequency Pulse
(X7)
6: Communication
Percentage Setting
F09.02=1: AI1
F09.02=2: AI2
F09.02=3: AI3
F09.02=4: AI4 (Expansion Card)
The specific percentage of PID feedback is directly determined by AI (percentage).
F09.02=5: High-Frequency Pulse (X7)
The specific percentage of PID feedback is directly determined by HDI (percentage)
Please refer to the description of F00.04 for detailed explanations of AI1-AI4 and
X7. When they are used for PID setting, their percentages are set values, with the
maximum output of 100.00%.
F09.02=6: Communication Percentage Setting
The specific percentage of PID feedback is directly determined by communication
(percentage).
 If inverter is under master-slave communication control (F10.05=1) and present
inverter is a slave (F10.06=0), the feedback percentage is “700FH (Master-Slave
Communication Setting) * F10.08 (Receiving Proportionality Factor of Slave)”.
The range of 700FH is -100.00% to 100.00%. See Table 12-2 for details.
 For general communication (F10.05=0), the feedback percentage is “7005 H
(Communication Setting of Process PID Feedback)”. The range of 7005 H is
-100.00% to 100.00%. See Table 12-2 for details.
No.
Function
Range
Unit
Default
Type
F09.04
PID
Positive/Negative
Action
0: Positive Action
1: Negative Action
0
〇
The action mode of the process PID is determined through the setting of F09.04 and
