EM500 Open-Loop Vector Control Inverter User Manual
341
No.
Function
Range
Unit
Default
Type
F27.01
Feedforward Gain
Effect channel
0: Feedforward Gain *Given
source B
1: Feedforward Gain *Given
source A
2: Feedforward Gain *10V
1
〇
F27.01=0: Feedforward Gain *Given source B
The feedforward gain acts through given source B.
F27.01=1: Feedforward Gain *Given source A
The feedforward gain acts through given source A
F27.01=2: Feedforward Gain *10V
The feedforward gain is directly multiplied by Fmax superimposed on the output
No.
Function
Range
Unit
Default
Type
F27.02
Feedforward Gain
input mode
0:Feedforward gain invariability
1: 0.00~Upper Limit feedforward
gain
2: -Upper Limit feedforward
gain~+ Upper Limit feedforward
gain
1
〇
F27.02=0:Feedforward gain invariability
Feedforward gain value is always by F27.05 set value.
F27.02=1: 0.00~Upper Limit feedforward gain
The feedforward gain is automatically adjusted from 0.00 ~F27.04 setting value.
F27.02=2:-Upper Limit feedforward gain~+ Upper Limit feedforward gain
The feedforward gain is automatically adjusted from - F27.04 ~ + F27.04 setting value.
Unlabeled defaults are the same as F27.00 = 0
No.
Function
Range
Unit
Default
Type
F27.03
Feedforward
Control
Ones Place:Feedforward reset
option
0: Automatic reset
1: Terminal reset
Tens Place:Feedforward power
10
〇
