EM500 Open-Loop Vector Control Inverter User Manual
172
Figure 7–5 Forward/Reverse Deadband Time
No.
Function
Range
Unit
Default
Type
F00.23
Carrier
Frequency
1.0 - 16.0 (inverter rated power 4 kW)
1.0 - 10.0 (inverter rated power 5.50 –
7.50 kW)
1.0 - 8.0 (inverter rated power 11.00 -
45.00 kW)
1.0 - 4.0 (inverter rated power 55.00 -
90.00 kW)
1.0 - 3.0 (inverter rated power 110.00 -
560.00 kW)
kHz
4.0
(7.5kW
and
below/2.
0)
●
Increasing carrier frequency can reduce motor noise, but it will increase inverter heat
as well. When the carrier frequency is higher than the default value, increasing the carrier
frequency by 1 kHz requires the load to decrease to some extent. Please set F00.24=1,
and at this time, inverter will automatically adjust the actual carrier frequency based upon
the actual condition.
It's recommend to set the relationship between inverter’s rated power and carrier
frequency as shown in Table 7–2.
Table 7-2 Setting Relationship between Inverter Rated Power and Carrier Frequency
Inverter Frequency
Pe
Pe≤4kW
5.5kW - 7.5kW
11kW -
45kW
55kW -
90kW
110kW -
560kW
Rated Carrier
4.0 kHz
2.0kHz
Maximum Carrier
16.0 kHz
10.0kHz
8.0kHz
4.0kHz
3.0kHz
No.
Function
Range
Unit
Default
Type
F00.24
Automatic
Adjustment of
Carrier
Frequency
0: Disabled
1: Enabled 1
2: Enabled 2
1
〇
F00.24=0: Disabled
Inverter judges the direction according to the status of terminal F/R and
the value set through F00.20. If the set forward direction is inconsistent
with the wished motor direction, switch any two of inverter’s output terminals
U, V and W, or change F00.20 to an inverse value.
