EM500 Open-Loop Vector Control Inverter User Manual
401
Function
41
Function
41
Register Address Hi
00
Register Address Hi
00
Register Address Lo
07
Register Address Lo
07
Register Value Hi
13
Register Value Hi
13
Register Value Lo
88
Register Value Lo
88
The data above means to change the set frequency (F00.07) to 50.00Hz, which will
take effect immediately, but will not be saved in EEPROM. After rewriting, inverter runs
at the frequency 50.00 Hz, but runs at the frequency set prior to change after inverter is
power on
12.3.3.60x10 Write multiple registers or commands
This function code is used to write continuous register blocks (1 to 16 registers) in a
remote device.
The value requested for writing is described in the request data field. Each register
divides the data into two bytes
The normal response is to return the function code, the initial address and the
number of registers written.

Request PDU
Function Code
1 byte
0x10
Initial Address
2 bytes
0x0000 - 0xFFFF
Number of Registers
2 bytes
1 - 16
Number of Bytes
1 byte
2×N*
Register Value
N*×2 bytes
N*=Number of Registers

Response PDU
Function Code
1 byte
0x10
Initial Address
2 bytes
0x0000 - 0xFFFF
Number of Registers
2 bytes
1 - 16

Incorrect PDU
Error Code
1 byte
0x90
Exceptional Code
1 byte
See Table12-4
The following is an example of requesting to write 00 01 and 00 03 in the two
