13.3.2.3 Write register or command function code, (0x600 , save EEPROM)
The function code is used to write the non-holding register. The request message is the
address and value to be written to the register. The normal status response message is the
slave address + exception code. The function code can write up to two registers at a time.
 request message
CAN-ID
0x600+slave address
DLC（Date Length）
4*N
Data Field
N*4 Bytes

Response message
CAN-ID
0x600+ Host address
DLC
（
Date Length
）
2
Data Field
Slave address+ Abnormal code(00)
 Error message
CAN-ID
0x680+ Host address
DLC（Date Length）
1
Data Field
Slave address+ Abnormal code
The following is an example of changing the device maximum frequency (F00.16) at
address 1 to 50.00Hz:
request
Response
Domain
Name
（hexadecimal）
Domain
Name
(normal)
（hexadecimal
）
Domain
Name
(Abnormal)
（hexadecimal）
CAN-ID
601
CAN-ID
67F
CAN-ID
6FF
Date
Length
04
Date
Length
02
Date
Length
02
