Sinee EM500 - F19 Group: Fault Record Parameter

EM500 Open-Loop Vector Control Inverter User Manual
314
Target Voltage
time. Range: 0.0 - Motor Rated Voltage.
F18.40
VF Separation
Output Voltage
Used to display VF separation output voltage in real
time. Range: 0.0 - Motor Rated Voltage.
V
F18.41
-
F18.50
Not Used
-100.0 ~ 100.0
F18.51
PID Output
In zero servo running status, this function code is
used to display present position offset. Range: -0 -
65535.
%
F18.60
Inverter
temperature
Temperature of inverter module ( it is normal that the
temperature is higher than the environment for 40) -
40 ~ 200
℃
7.20 F19 Group: Fault Record Parameter
This group of parameters can be used for viewing the types of the last three faults
and the status of inverter at fault, but cannot be operated.

Function codes related to the information about the last fault:
No.
Function
Range
Unit
Default
Type
F19.00
Last Fault Type
Display the last fault type. See
Table 7-22 Fault Types
0
×
F19.01
Output Frequency
at Fault
Used to display output frequency
at the last fault.
Hz
0.00
×
F19.02
Output Current at
Fault
Used to display output current at
the last fault.
A
0.00/0.0
×
F19.03
Bus Voltage at
Fault
Used to display bus voltage at the
last fault.
V
0
×
F19.04
Running Mode at
Fault
Used to display the running status
at the last fault. See Table 7-23
Running Modes at Fault
0
×
F19.05
Working Time at
Fault
Used to display the working time
at the last fault.
h
0
×

Function codes related to the information about the last fault:
No.
Function
Range
Unit
Default
Type
F19.06
Last Fault Type
Display the last fault type. See
Table 7-22 Fault Types.
0
×
F19.07
Output Frequency
at Fault
Display output frequency at the
last fault.
Hz
0.00
×
