EM500 Open-Loop Vector Control Inverter User Manual
313
F18.27
AI2
Used to display the standard value of present analog
input channel 2 (AI2) corresponding to 100.0%.
Range: 0.0 - 100.0.
%
F18.28
AI3
Used to display the standard value of present analog
input channel 3 (AI3) corresponding to 100.0%.
Range: 0.0 - 100.0.
%
F18.29
AI4
Used to display the standard value of present analog
input channel 4 (AI4) corresponding to 100.0%.
Range: -100.0 - 100.0.
★ Analog input terminal AI4 is an expansion card
(EC-IO-A1) terminal. Please perform configuration
before use.
%
F18.30
Communication
Setting
Not used
%
F18.31
High-Speed Pulse
Input Frequency:
kHz
Used to display the input pulse frequency of present
high-speed pulse input channel HDI (X7). Minimum
resolution: 0.01 kHz. Range: 0.00 - 100.00.
kHz
F18.32
High-Speed Pulse
Input Frequency:
Hz
Used to display the input pulse frequency of present
high-speed pulse input channel HDI (X7). Minimum
resolution: 1 kHz. Range: 0 - 65535. If actual input
frequency > 65535 Hz, display value is 65535.
Hz
F18.33
Count Value
Used to display the number of input pulses of present
high-speed pulse input channel HDI (X7). See
F16.03 and F16.04. Range: 0 - F16.03.
F18.34
Actual Length
Used to display the actual length of the workpiece
being processed (by transformation from HDI (X7)
as per relevant setting) of input pulses of present
high-speed pulse input channel HDI (X7). See
F16.01 and F16.02. Range: 0 - F16.01.
m
F18.35
Remaining Time
of Timed Run
Used to display the remaining time of the timed run.
See F16.05. Range: 0.0 - F16.05.
min
F18.36
Position of Rotor
of Synchronous
Motor
Position of rotor of synchronous motor. Range: 0.0 -
359.9.
°
F18.37
Rotary
Transformer
Position
Used to display the rotary transformer position.
Range: 0 - 4095.
F18.38
Motor
Temperature
Used to display motor temperature collected by the
analog channel 4 (AI4). Range: 0 - 200.
℃
F18.39
VF Separation
Used to display VF separation target voltage in real
V
