Sinee EM500 - Preset PID Setting Function

EM500 Open-Loop Vector Control Inverter User Manual
256
Table 7-16 Preset PID Setting Function
No.
Function
Range
Unit
Default
Type
F09.35
The Feedback
Voltage Upper Limit
The feedback voltage lower
limit~10.00
V
10.00
●
F09.36
The Feedback
Voltage Lower Limit
0.00~ The Feedback Voltage
Upper Limit
V
0.00
●
The feedback voltage upper and lower limits can be used for automatic Material
supply disruptions detection of the winding application, which represent the upper and
lower bounds of the Material supply disruptions, respectively. Due to the particularity of
the winding application, F09.35 and F09.36 can be Used to reflect the real sensor
boundaries, which is more conducive to system stability.
No.
Function
Range
Unit
Default
Type
F09.37
PID
I
ntegral
A
ction
Choice Given Change
Time
0: Always calculated
integral item
1: F09.21 began calculating
integral item When set time
has arrived
2: when the error is less
than F09.38 Start
calculating integral item
0
●
F09.38
PID Integral Action
G
iven
C
hange
T
time
Input Deviation
0.00-100.00
%
30.00
●
F09.37=0: Always calculated integral item
This function code does not affect the integral effect
F09.37=1 F09.21 began calculating integral item When set time has arrived
The first F09.21 changes within the time set after starting does not work
F09.37=2 when the error is less than F09.38 Start calculating integral item
100.00%
6
485
-100.00% -
100.00%
-100.00% - 100.00%
Disabled
Enabled
--
F09.32
0.0 - F09.03
0.00% - 100.00%
Enabled
Disabled
--
F09.33
0.0 - F09.03
0.00% - 100.00%
Enabled
Enabled
--
F09.34
0.0 - F09.03
0.00% - 100.00%
