EM500 Open-Loop Vector Control Inverter User Manual
255
★During the delay, PID continues the output;
After the delay, function code sets output.
Judge the awakening condition: If the absolute
value of the feedback >= the awakening action
point (F09.28) and this status is maintained for the
awakening delay time (F09.31), inverter exits the
sleep mode
★During the delay, function code sets output;
after the delay, PID continues with the normal
output
Recommendation: During the positive action, F09.28 (awakening action point) ≥ F09.30
(awakening action point); during negative action, F09.28 (awakening action point) ≤
F09.30 (awakening action point).
0.0 – PID Setting Feedback
Range F09.03
0.0 – PID Setting Feedback
Range F09.03
0.0 – PID Setting Feedback
Range F09.03
These function codes are used for PID setting together with the function code.
EM500 inverter has the preset PID setting function, for which the switching condition is
mainly determined by the input function “15: Preset PID Terminal 1” and “16: Preset PID
Terminal 2”. See Table 7-16 for details.
