EM500 Open-Loop Vector Control Inverter User Manual
286
physical meaning with normal running
The trigger conditions for JOG running command depend upon inverter control
modes. See Table 7-20 for details.
Table 7-20 JOG Running Command
Command Source
Options (F00.02)
JOG Running Command
0: Keypad Control
M.K (F12.00) can be set as “1: FJOG” or “2: RJOG”.
Press , then JOG running command is enabled;
release , then JOG running command is disabled.
★ Remove the keypad during JOG running to stop
inverter
1: Terminal Control
Numeric input terminal function “4: FJOG” or “5: RJOG”.
Under default conditions, if the function terminal is enabled,
JOG running command is active; if the function terminal is
disabled, JOG running command is inactive.
2: Communication
Control
If host controller writes “0003H: FJOG” or “0004: RJOG”
in the register 7000H through MODBUS protocol, JOG
running command will be active; writes “0007H: coast to
stop”, JOG running command will be inactive.
No.
Function
Range
Unit
Default
Type
F15.03
Acceleration Time 2
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.04
Deceleration Time 2
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.05
Acceleration Time 3
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.06
Deceleration Time 3
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.07
Acceleration Time 4
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.08
Deceleration Time 4
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
s
15.00
●
