EM500 Open-Loop Vector Control Inverter User Manual
161
54: Switch Main
Frequency Source to AI3
If enabled, main frequency source A is
determined by the percentage inputted through
AI3; it works the same way as that for
F00.04=3.
5
55: Switch Main
Frequency Source to
High-Frequency Pulse
Input
If enabled, main frequency source A is
determined by the percentage inputted through
high-frequency pulse input; it works the same
way as that for F00.04=5.
6
56: Switch Main
Frequency Source to
Communication Setting
If enabled, main frequency source A is
determined through communication; it works
the same way as that for F00.04=6.
7
--
If neither of terminals above is enabled, main
frequency source A is determined through
F00.04.
8
No.
Function
Range
Unit
Default
Type
F00.05
Auxiliary
Frequency
Source B
0: Numeric Frequency
Setting F00.07
1: AI1
2: AI2
3: AI3
4: AI4 (Expansion Card)
5: High-Frequency Pulse
Input (X7)
6. Auxiliary Frequency
Communication
Percentage Setting
7. Direct Auxiliary
Frequency
Communication Setting
8: digital Potentiometer
9: Not Used
10: Process PID
11: Simple PLC
0
〇
F00.05=0: Numeric Frequency Setting F00.07
Auxiliary frequency source B is determined through numeric frequency setting
F00.07.
F00.05=1: AI1
