EM500 Open-Loop Vector Control Inverter User Manual
101
F06.45
F06.46
Synchronous Motor
speed tracking
proportional gain
0.00～10.00
1.00
〇
F06.47
Synchronous Motor
speed tracking
integral gain
0.00～10.00
1.00
〇
F06.48
Synchronous Motor
speed tracking filter
time
0.00～10.00
ms
0.40
〇
F06.49
Synchronous Motor
speed tracking
control Coefficient
1.0～100.0
5.0
〇
F06.50
Synchronous Motor
speed tracking
control threshold
0.00
～
10.00
0.20
〇
F07
Protection Function Setting Group
F07.00
Protection block
E20
E22
E13
SlU
SOU
SOC
IlP
OlP
000
00000
〇
0: Valid Protection
1: Protection blocked
F07.01
Motor Overload
Protection Gain
0.20 - 10.00`
1.00
●
F07.02
Motor Overload
Pre-Alarming Factor
50 - 100
%
80
●
F07.03
Motor Temperature
Sensor Type
0: No Temperature Sensor
1: PT100
2: PT1000
3: KTY84-130/150
4: PTC130/150
0
●
F07.04
Motor Overheating
Protection
Threshold
0 - 200
℃
110
●
F07.05
Motor Overheating
Pre-Alarming
Threshold
0 - 200
℃
90
●
F07.06
Bus Voltage Control
Options
0: Disabled
1: Undervoltage Stall, Enabled
2: Overvoltage Stall, Enabled
3: Overvoltage Stall and Undervoltage
Stall, Enabled
2
〇
