EM500 Open-Loop Vector Control Inverter User Manual
100
Gain of Injection
Current
F06.31
Integral Time of
Low Frequency
Range Regulator of
Injection Current
0.00 - 300.00
ms
10.00
●
F06.32
Frequency of
Injection Current at
High Frequency
Range
0.00 - 100.00 (100.00= Motor Rated
Frequency)
%
20.00
●
F06.33
Injection Current at
High Frequency
Range
0.0 - 30.0 (100.0= Motor Rated
Current)
%
8.0
●
F06.34
High Frequency
Range Regulator
Gain of Injection
Current
0.00 - 10.00
0.50
●
F06.35
Integral Time of
High Frequency
Range Regulator of
Injection Current
0.00 - 300.00
ms
10.00
●
F06.36
Synchronous motor
current loop
proportional gain
10.00～600.00
%
100.00
〇
F06.37
Synchronous motor
current loop integral
gain
10.00～600.00
%
100.00
〇
F06.38
~
F06.40
Not Used
F06.41
Low frequency
Mode
0: mode 0
1: mode 1
2-3: Not Used
0
〇
F06.42
Low frequency
processing
frequency
0.0～50.0
%
8.0
〇
F06.43
Sink Current
0.0
～
600.0
%
80.0
〇
F06.44
~
Not Used
