EM500 Open-Loop Vector Control Inverter User Manual
99
2: No output
F06.18
SVC Zero
Frequency
Band-Type Brake
Current
50.0 - 400.0 (100.0=Idling Current)
%
100.0
〇
F06.19
Not Used
F06.20
Voltage
Feedforward Gain
0 - 100
%
0
●
F06.21
Field Weakening
Control Options of
Synchronous Motor
0: Disabled
1: Direct Calculation
2: Automatic Adjustment
1
〇
F06.22
Field Weakening
Factor of
Synchronous Motor
100.00 - 200.00
%
100.00
●
F06.23
Maximum Field
Weakening Current
of Synchronous
Motor
0.0 - 150.0 (100.0= Motor Rated
Current)
%
50.0
●
F06.24
Proportional Gain of
Field Weakening
Regulator of
Synchronous Motor
0.00 - 10.00
0.50
●
F06.25
Integral Time of
Field Weakening
Regulator of
Synchronous Motor
0.00 - 6000.00
ms
100.00
●
F06.26
MTPA Control
Options of
Synchronous Motor
0: Disabled
1: Enabled
0
〇
F06.27
Gain of Autotuning
at Initial Position
0 - 600
%
80
●
F06.28
Frequency of
Injection Current at
Low Frequency
Range
0.00 - 100.00 (100.00= Motor Rated
Frequency)
%
10.00
●
F06.29
Injection Current at
Low Frequency
Range
0.0 - 60.0 (100.0= Motor Rated
Current)
%
20.0
●
F06.30
Low Frequency
Range Regulator
0.00 - 10.00
0.50
●
