EM500 Open-Loop Vector Control Inverter User Manual
98
Frequency 1
F06.05
Switching
Frequency 2
Switching Frequency 1 - Maximum
Frequency F00.16
Hz
10.00
●
F06.06
Speed Loop
Anti-Saturation
Factor
0.000 - 1.000
0.500
●
F06.07
Time Constant of
Output Filter of
Speed Loop
0.000 - 0.100
s
0.001
●
F06.08
Vector Control Slip
Gain
50.00 - 200.00
%
100.00
●
F06.09
Speed   control
torque limit source
selection
0: F06.10 and F06.11
1: AI1
2: AI2
3: AI3
4: AI4 (Expansion Card)
5: communication
6: maximum of AI2 and AI3
7: minimum of AI2 and AI3
0
〇
F06.10
Upper Limit of
Electric Torque for
Speed Control
0.0 - 250.0
%
165.0
●
F06.11
Upper Limit of
Brake Torque for
Speed Control
0.0 - 250.0
%
165.0
●
F06.12
Excitation Current
Proportional Gain
ACR-P1
0.00 - 100.00
0.50
●
F06.13
Excitation Current
Integral Time
Constant ACR-T1
0.00 - 600.00
0.00: No Integral
ms
10.00
●
F06.14
Torque Current
Proportional Gain
ACR-P2
0.00 - 100.00
0.50
●
F06.15
Torque Current
Integral Time
Constant ACR-T2
0.00 - 600.00
0.00: No Integral
ms
10.00
●
F06.16
Position Loop Gain
0.000 - 40.000
1.000
●
F06.17
SVC Control Mode
at Zero Frequency
0: Brake
1: Normal
2
〇
