Sinee EM500 - Installation Dimensions for Flush Mounting

EM500 Open-Loop Vector Control Inverter User Manual
35
(b)
Figure 2-8 Installation Dimensions for Flush Mounting
Table 2-3 Installation Dimensions for Flush Mounting
Model No.
W
W1
H
H1
H2
D
D1
D2
D3
d
Frame
EM500-5R5G/7R5P-3B
188
166
300
278
258
172
128
172
90
5.5
a
EM500-7R5G/9R0P-3B
EM500-011G/015P-3B
224
150
431
409
343
210
165
210
122
8
a
EM500-015G/018P-3B
EM500-018G/022P-3B
EM500-022G/030P-3/3B
250
200
484
470
440
214
150
222
122
6.5
b
EM500-030G/037P-3/3B
EM500-037G/045P-3/3B
EM500-045G/055P-3/3B
315
220
560
546
513
242
180
250
140
7
b
EM500-055G/075P-3/3B
350
250
662
638
603
254
188
262
138
12
b
EM500-075G/905P-3/3B
EM500-090G/110P-3
386
300
753
724
700
287
231
295
136
13
b
EM500-110G/132P-3
416
300
855
825
793
302
246
310
132
13
b
EM500-132G/160P-3
EM500-160G/185P-3
497
397
1107
1076
1036
335
285
343
145
13
b
EM500-185G/200P-3
EM500-200G/220P-3
