EM500 Open-Loop Vector Control Inverter User Manual
95
F04.15
S Curve Start
Section Time at
Acceleration
0.00 - System acceleration time/2
(F15.13=0)
0.0 - System acceleration time/2
(F15.13=1)
0 - System acceleration time/2
(F15.13=2)
s
1.00
●
F04.16
S Curve End Section
Time at Acceleration
0.00 - System acceleration time/2
(F15.13=0)
0.0 - System acceleration time/2
(F15.13=1)
0 - System acceleration time/2
(F15.13=2)
s
1.00
●
F04.17
S Curve Start
Section Time at
Deceleration
0.00 - System deceleration time/2
(F15.13=0)
0.0 - System deceleration time/2
(F15.13=1)
0 - System deceleration time/2
(F15.13=2)
s
1.00
●
F04.18
S Curve End Section
Time at
Deceleration
0.00 - System deceleration time/2
(F15.13=0)
0.0 - System deceleration time/2
(F15.13=1)
0 - System deceleration time/2
(F15.13=2)
s
1.00
●
F04.19
Stop Mode
0: Ramp-To-Stop
1: Coast-to-Stop
0
〇
F04.20
DC Brake Start
Frequency at Stop
0.00 - Maximum Frequency F00.16
Hz
0.00
〇
F04.21
DC Brake Current at
Stop
0.0 - 150.0 (100.0= Motor Rated
Current)
%
100.0
〇
F04.22
DC Brake Time at
Stop
0.00 - 30.00, Disabled at 0.00
s
0.00
〇
F04.23
DC Brake Field
Weakening Time at
Stop
0.00 - 30.00
s
0.50
〇
F04.24
Magnetic Flux
Brake Gain
100 – 150 (100: No Magnetic Flux
Brake)
100
〇
F04.25
Not Used
F04.26
Start Mode after
Fault/Coast to Stop
0: Start as per Set Mode of F04.00
1: Rotation Speed Tracking Start
0
〇
