1
Set frequency
(absolute value)
0.00 Hz - Fmax, corresponding output 0.0% - 100.0%
2
Output torque
(absolute value)
0.0% - 200.0%, corresponding output 0.0% - 100.0%
3
Set torque (absolute
value)
0.0% - 200.0%, corresponding output 0.0% - 100.0%
4
Output Current
0.0A - 2*Ie, corresponding output 0.0% - 100.0%
5
Output Voltage
0.0V - 1.5*Ue, corresponding output 0.0% - 100.0%
6
Bus voltage
0V - 1000V, corresponding output 0.0% - 100.0%
7
Output Power
0.00kW - 2*Pe, corresponding output 0.0% - 100.0%
8
AI1
Output the actual input voltage, other than the results
after offset
0.0% - 100.0%, corresponding output 0.0% - 100.0%
9
AI2
10
AI3
11
AI4 (Expansion Card)
12
High-Speed Pulse
Input
F02.26 - F02.28, corresponding output 0.0% - 100.0%
13
Not Used
14
The Count Value
0~F16.03 corresponding output F16.10~F16.11
15
Length Value
0~F16.01 corresponding output F16.10~F16.11
16
The PID Output
Percentage
-100.0%~100.0% corresponding output 0.0%~100.0%
18
PID Feedback
-100.0%~100.0% corresponding output 0.0%~100.0%
19
PID Is Given
-100.0%~100.0% corresponding output 0.0%~100.0%
20~37
Not Used
38
The Fan Speed Output
Air compressor special function0%~100%
Corresponding to the maximum frequency inverter for
fan
★
Fmax, Maximum Frequency (F00.16)
Ie, Inverter Rated Current (F12.21)
Ue, Inverter Rated Voltage (F12.20)
Pe, Inverter Rated Power (F12.19)
The output of the analog output terminal can be switched through DIP between the
voltage signal 0.00V - 10.00 V and the current signal 0.00mA - 20.00mA. For voltage
signal, 0.0% - 100.0% corresponds to the output 0.00V - 10.00 V; for current signal,
0.0% - 100.0% corresponds to 0.00mA - 20.00mA. See 3.3.7 Analog Output Terminal
