“RUN”
source, inverter executes the function F/R according to the
setting value of the terminal control mode F00.03 under the
condition that the function terminal is enabled. (See F00.03
Function Code)
2
Direction R/F
If the terminal control (F00.02=1) is selected as the command
source, inverter executes the function F/R according to the
setting value of the terminal control mode F00.03 under the
condition that the function terminal is enabled. (See F00.03
Function Code)
3
3-Wire Sequence
Stop Control
If the terminal control (F00.02=1) is selected as the command
source and the terminal control mode is 3-wire sequence
control (F00.03=2/3), inverter executes the stop command
under the condition that the function terminal is enabled. (See
F00.03 Function Code)
4
Forward JOG
(FJOG)
If the command source is selected as terminal control
(F00.02=1), inverter runs forward under the condition that
FJOG function terminal is enabled. Inverter runs reversely, if
RJOG function terminal is enabled. If both FJOG and RJOG
are enabled at the same time, inverter will ram to stop. See
Figure Table 7-20.
★
If reverse is prohibited, FJOG is disabled.
5
Reverse JOG
(RJOG)
6
Terminal UP
If the function terminal UP is enabled, the frequency offset
will increase at the speed defined through F12.11; if the
function terminal DOWN is enabled, the frequency offset will
decrease at the speed defined through F12.11.
If UP/DOWN offset clear terminal is enabled, the frequency
offset will be cleared;
Setting source of the final frequency source A = Setting
frequency of the frequency source A + UP/DOWN offset.
★
The UP/DOWN function is only enabled when main
frequency source A is involved in setting; The offset
frequency can be viewed through F18.15.
The terminal UP/DOWN has the same function as UP/DOWN
on the keypad.
7
Terminal DOWN
8
UP/DOWN Offset
Clear
9
Coast-to-Stop
Inverter will be blocked for output and coast to stop, if this
function terminal is enabled during the running. At this time,
inverter is not controlled by inverter.
10
Fault Reset
This terminal can be used for reset if inverter fails and the
failure is remedied. It has the same functions as the reset
button on the keypad.
