EM500 Open-Loop Vector Control Inverter User Manual
16
Torque Boost
Fixed torque boost curve, customer defined V/F curve scaling
Start Torque
150%/ 1 Hz (
VVF
), 150%/
0.25
Hz (
SVC
)
Torque Control
Accuracy
±
8
% rated torque (
SVC
)
AVR
Output voltage remains unchanged basically and input
voltage varies when AVR is active
Automatic
Current Limit
Automatically limit output current to avoid frequently
overcurrent trip.
DC Brake
Brake frequency: 0.01 - Maximum frequency, brake time: 0 -
30S
Brake current: 0% - 100% rated current
Signal Input
Source
Communication, preset speed, analog, high-speed impulse
Function
of Input
and Output
Reference
Power Supply
10V/20mA
Terminal
Control Power
Supply
24V/200mA
Numeric Input
Terminal
7 (standard X1 - X7) + 4 (expansion card X8 - X11) numeric
multi-functional input terminals:
X7 can be selected as high-speed impulse input terminal
(
F02.06=35/38/40
);
X1 - X6 and X8 - X11 (10 in total) can be used as common
digital input terminals.
Analog Input
Terminal
3 (standard
AI1
-
AI3
) + 1 (expansion card
AI4
) analog
input terminals:
1 (AI1) voltage source 0 - 10 input;
2 (AI2/AI3) voltage source 0 - 10V inputs or current
source 0 - 20mA input;
1 (AI4) voltage source -10V - 10V input
Numeric Output
Terminal
2 (standard
Y1/Y2
) + 1 (expansion card Y3) OC
multi-functional outputs and 2 (
R1: EA/EB/EC and R2:
RA/RB/RC
) relay multi-functional outputs.
Maximum output current of OC: 50mA; relay contact
capacity: 250VAC/3A or 30VDC/1A. When the relay works,
EA-EC and RA-RC are on, but EB-EC and RB-RC are off.
Analog Output
Terminal
M1 is with output 0 - 10V only.
M2 is with output 0 - 10V or 0 – 20 mA.
Keypad
Display
LED
LED displays relevant information about inverter.
Parameter Copy
Upload and download parameter setting information of
inverter to realize rapid copy.
Protection
Protection
Short circuit, overcurrent, overvoltage, undervoltage, phase
loss, overload, overheating, overspeed, offload, external fault,
etc.
