EM500 Open-Loop Vector Control Inverter User Manual
134
Delay Time
F17.16
VX3 Ineffective
Delay Time
0.000 - 30.000
s
0.000
●
F17.17
VX4 Effective
Delay Time
0.000 - 30.000
s
0.000
●
F17.18
VX4 Ineffective
Delay Time
0.000 - 30.000
s
0.000
●
F17.19
VY1 Virtual Output
Function
Same as numeric output terminal
function of F03 group
0
〇
F17.20
VY2 Virtual Output
Function
0
〇
F17.21
VY3 Virtual Output
Function
0
〇
F17.22
VY4 Virtual Output
Function
0
〇
F17.23
VY5 Virtual Output
Function
0
〇
F17.24
VY6 Virtual Output
Function
0
〇
F17.25
VY7 Virtual Output
Function
0
〇
F17.26
VY8 Virtual Output
Function
0
〇
F17.27
Positive/Negative
Logic of Virtual
Input
D7
D6
D5
D4
D3
D2
D1
D0
000
00000
〇
VY8
VY7
VY6
VY5
VY4
VY3
VY2
VY1
0: Positive Logic, Enabled at On/
Disabled at Off
1: Negative Logic, Disabled at On
/Enabled at Off
F17.28
Virtual Output
Terminal Control
D7
D6
D5
D4
D3
D2
D1
D0
111
11111
〇
VY8
VY7
VY6
VY5
VY4
VY3
VY2
VY1
0: To be determined by the status of
X1 – X7(No VY8)
1: To be determined by the output
function status
F17.29
VY1 Effective
Delay Time
0.000 - 30.000
s
0.000
●
F17.30
VY1 Ineffective
0.000 - 30.000
s
0.000
●
