GLOBAL CONFIG
CV MODE: 8 TRACKS
In “8 tracks” mode, each of the eight tracks has a dedicated CV/Gate output pair.
For SYNTH type patterns, the outputs produce CV and Gate signals that correspond to
the programmed pattern using pitch 1 for each step.
For DRUM type patterns, the output is tied to the EXT drum instrument. The outputs
produce a trigger from the GATE/TRIG output and an accent trigger from the CV/VEL
output.
For CONTROL type patterns, the output is tied to the control value 1. The outputs
produce a trigger from the GATE/TRIG output and a control voltage from the CV/VEL
output.
 USER GUIDE 201
ENGINE CV OUTPUT EXPANSION
SYNTH TYPE PATTERN
ON TRACK 1
PITCH 1 CV
PITCH 1 GATE
ENGINE CV OUTPUT EXPANSION
DRUM TYPE PATTERN
ON TRACK 1
EXT INST ACCENT
EXT INST TRIGGER
ENGINE CV OUTPUT EXPANSION
CTRL TYPE PATTERN
ON TRACK 1
CTRL 1 VALUE
CTRL 1 GATE
