Social Entropy Engine - CV;Gate Output Modes

TRACKS
CV/GATE OUTPUT MODES
When the CV/Gate output expansion board is installed, each track can be configured to
send out CV using either 1Volt/Octave, Hz/Volt or 1.2V/Octave and Gate using either
positive trigger or negative trigger. This allows the CV outputs to be used with a wide
range of different analog devices. Each of the eight tracks can have a different setting for
CV MODE.
The available modes are:
POSITIVE GATE,
1V/OCTAVE
Positive gate, 1 volt per octave
NEGATIVE GATE,
1V/OCTAVE
Negative gate, 1 volt per octave
POSITIVE GATE,
Hz/V
Positive gate, hertz per volt
NEGATIVE GATE,
Hz/V
Negative gate, hertz per volt
POSITIVE GATE,
1.2V/OCTAVE
Positive gate, 1.2 volts per octave
NEGATIVE GATE,
1.2V/OCTAVE
Negative gate, 1.2 volts per octave






 USER GUIDE 58
NOTE: The CV MODE can only be set when the CV/Gate expansion
board is installed and enabled.
