Social Entropy Engine - CV Mode: 4 Tracks

GLOBAL CONFIG
CV MODE: 4 TRACKS
In “4 tracks” mode, you can choose four tracks to share the outputs. Each selected track
will have two output pairs.
To select the four assigned tracks, when setting CV MODE to “4 tr”, click the track select
buttons to turn on/off four tracks.
For SYNTH type patterns, the outputs produce CV and Gate signals on one output pair
The second output pair generates an accent trigger on GATE/TRIG and a variable
velocity voltage on CV/VEL.
 USER GUIDE 202
ENGINE CV OUTPUT EXPANSION
SYNTH TYPE PATTERN
ON TRACK 1
PITCH 1 CV
PITCH 1 GATEPITCH 1 ACCENT
PITCH 1 VEL
