GLOBAL CONFIG
For DRUM type patterns, the outputs are tied to the EXT and BD drum instruments. The
outputs produce triggers from the GATE/TRIG outputs and accent triggers from the CV/
VEL outputs.
For CONTROL type patterns, the outputs are tied to control values 1 and 2. The outputs
produce gate signals from the GATE/TRIG outputs and control voltages from the CV/VEL
outputs.
 USER GUIDE 203
ENGINE CV OUTPUT EXPANSION
DRUM TYPE PATTERN
ON TRACK 1
EXT INST ACCENT
EXT INST TRIGGERBD INST TRIGGER
BD INST ACCENT
ENGINE CV OUTPUT EXPANSION
CTRL TYPE PATTERN
ON TRACK 1
CTRL 1 VALUE
CTRL 1 GATECTRL 2 GATE
CTRL 2 VALUE
