Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
Operation 5-135
Document generated: 10.10.14
SW V6.0
5.10.9.2 Standalone Systems
Of course, the concept described above also works for a standalone console.
However, for a standalone console without central user management the
server is not required. The user extension runs locally on the core sub-system,
and it can be configured (in the user.xml file) to provide up to 64 users
and 16 policies.
If more users or policies are required, or if users need to be managed centrally
even on a standalone system, an additional sub-system must be started on the
server to run the central user extension. The user extension running locally
then only provides the Admin and Default user’s parameters, as described
above.
User Extension
on:
Users
max.
Policies
max.
Comment
Standalone Console:
Console 64* 16**
As specified by the user.xml file
(Defaults: *20 and **8, resp.)
With Central User
Management Server:
Console 2 2
User configurations of the Admin and the
default users are replicated to each console
Server 4096 255 As specified by the user.xml file
5.10.9.3 In Case of a Failure...
Failure of the central user management server or the network connection has
the following consequences:
  • LoginispossibleasAdminonly.
  • Theconfigurationtoolprovidesaccesstothelocaluserconfigurationonly
(i.e. for the Admin and the Default user). A user configuration made while
the central user management server or the network connection is down
will be overwritten as soon as the central user extension re-appears on the
network.
But: • No consequences for the privileges of the user currently logged in, as they
are saved on the sub-system locally.
  • Logoutremainspossible.
