OnAir 3000 Digital Mixing Console
Operation 5-145
Document generated: 10.10.14
SW V6.0
5.12.4.3 I/O 21
Error Code Error Type Error Text / Comment
3001
Info
I/O 21, Rack “Int”: Reconfiguration required.
Appears during power-up and runtime together with 3006.
3002
Info
I/O 21, The Rack “Ext 1” was reconfigured. Please make sure, the CORE is rebooted in order to achieve
system consistency.
3003
Warning
I/O 21, Slot change: Card from Slot 2 of the rack ‘Internal’ removed.
Appears during power-up and runtime if a card was removed.
3004
Info I/O 21, Slot change: Same Card in Slot 2 of the rack ‘External 1‘ re-installed.
3005
Info I/O 21, Slot failure: The Card in Slot 13 must be a GPIO Card.
3006
Info
I/O 21, Slot change: Card to Slot 2 added. Please reconfigure the rack ‘Internal‘ and reboot the CORE in
order to achieve system consistency.
Appears during power-up and runtime if a card was added.
3007
Warning I/O 21, Slot failure: Unknown Card found. Card in Slot 3 of the rack ‘D21m Rack 1‘ not supported.
3008
Warning I/O 21, Secondary power failure: Analog Power. (Rack ‘External 2’)
3009
Warning I/O 21, Secondary power failure: Digital Power. (Rack ‘External 2’)
3010
Warning
I/O 21, Primary Power Supply 1 failed. (Rack ‘External 1’)
Appears if power fails at the 1st primary power supply (Fail), but not in cases where the power supply is
removed (Present).
3011
Warning
I/O 21, Primary Power Supply 2 failed. (Rack ‘Internal’)
Appears if power fails at the 2nd primary power supply (Fail), but not in cases where the power supply is
removed (Present).
3012
Warning
I/O 21, Fan failure. (Rack ‘Internal’).
Appears during power-up and runtime if the fan connected to the first primary power supply of the corre-
sponding rack fails.
Note: Only the fan connected to the first primary power supply can be monitored.
3013
Warning I/O 21, Could not open port COMX.
3014
Error
I/O 21, Missing D21m rack ’External 1’.
Appears during power-up if the communication to a D21m rack cannot be established.
Not in case of predefined stage boxes (D21m.XML).
3015
Warning
I/O 21, Fan unit disconnected. (Rack ‘Internal’).
Appears during runtime if the fan connected to the first primary power supply of the corresponding rack is
disconnected.
Note: Only the fan connected to the first primary power supply can be monitored.
3016
Warning
I/O 21, Communication to rack ‘Internal‘ lost.
Appears if the communication to a D21m rack is lost. Not in case of predefined stage boxes (D21m.XML).
3017
Warning
I/O 21, Temperature Alarm in D21m rack ‘Internal‘.
Appears, if the temperature in the specified rack exceeds approximately 70°C.
3018
Info
I/O 21, Invalid module on merger port 13
Appears during power-up if an unsupported module is connected to the D21m merger, e.g. a desk module.
Supported modules are Rack (D21M_LVDS_HD_CARD) and StageBox (D21M_MADI_HD_CARD).
3021
Error
I/O 21, Card in slot 2 of rack ‘External 3’ is not allowed in this slot. It is not possible to load a consistent
configuration.
Appears during power-up if a mic card or a double-slot card is detected in a even slot (e.g. slot 2 instead
of slot 1). This is a serious problem, because the HD LINK mapping is wrong in this case. The user has to
change the D21m I/O card into a correct slot.
3022
Info
I/O 21, Additional HD Link to a DSP card required. Rack ‚Int’ provides 128 inputs, but only 96 channels are
connected to the CORE. 32 inputs not available.
Appears during power-up if not enough HD link channels to the DSP cards are available. E.g. there are 3
MADI cards (3*64 channels), but only one HD link (with 96 channels total).
