Studer OnAir 3000 User Manual

A/B Desk Configuration 7-9
OnAir 3000 Digital Mixing Console
Document generated: 10.10.14
SW V6.0
7.3.3 Initial Settings
To avoid inconsistencies during A/B Desk Mode configuration, it is strongly
recommended to perform the following preparations in advance.
User GUI:
Channel FDR/bus page, input routing page, output routing page
  • MakesurethatallbusassignmentsareOFF(PGMA,PGMB,REC,AUX,
N–X) and the contribution levels are set to ‘Mute’
  • Clearthewholeinputrouting(stripassignment)
  • Clearthewholeoutputrouting
After having configured the desk resource definition, it will be impossible to
modify certain strip assignments, output routings and bus assignments.
7.4 Configuration
The following chapter is a check list guiding the system administrator through
all the configuration settings required for a proper A/B Desk Mode configura-
tion.
7.4.1 Desk
Desk_ModuleTable.xml
For each of the two desks, the Desk_ModuleTable.xml file must be
configured in such a way that:
  • theStripChannels(FirstStripNo)areassignedtothemodulesasdefined
in the AB DESK Mode Desk Resources.xls form.
  • themodulelocations(Location)areasdefinedinthe AB DESK Mode
Desk Resources.xls form
  • theprimarydeskislocatedinDeskGroup1,andthesecondarydeskis
located in DeskGroup 2
  • thekeymapping(MappingPattern)correspondstothelocation
Normally, CR (control room) monitoring is used for the Primary Desk, and
ST1 (Studio 1) monitoring is used for the Secondary Desk. Studios 2 and 3
can be assigned to any of the desks.
Primary and secondary desks usually have their own desk group, defining
which input groups (MIC, LINE, …) are selectable with the input selector
rotary encoder on the fader module.
Desk_KeyMapping.xml
Some key mapping patterns have to be adapted for certain functions:
  Next function buttons: There exists a set of two desk functions, one for
the primary desk (NextA, StartNextA) and one for secondary desk (NextB,
StartNextB)
OnAir: Instead of using the OnAir desk key function, the primary desk
usually needs OnAirPGMA, the secondary desk OnAirPGMB
