Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
9-14 Networking
Document generated: 10.10.14
SW V6.0
9.4.2 Systems with Livewire
The topologies described in this chapter provide a control network for OnAir
consoles and administrative PCs and a dedicated network or VLAN for
Livewire network nodes.
(Livewire and the Livewire logo are trademarks of Axia Audio and Telos
Systems).
The following table provides an overview:
DHCP NTP WINS
Management
Console
IT-Network
Access
Internet
Access
Central Server and
Control Systems
MC BC
Standa-
lone
Multi
Console
Yes No No control network No No typically not needed Yes Yes
Single
Console
No No No control network No No typically not needed Yes Yes
Inte-
grated
IT network IT network IT network IT network Yes Yes IT network Yes Yes
Routed IT network IT network IT network IT network Yes Yes IT network Yes No
For the OnAir Control network, we recommend to allocate IP addresses
according to the following class–B network scheme, to which all switch
configurations as well as OnAir consoles and Livewire cards provided by
Studer comply:
From To Standalone/Inte-
grated Topology
Routed Topology Comment
XXX.YYY.000.001 Master Switch Router Gateway
XXX:YYY.000.002 XXX:YYY.000.009 additional managed switches
XXX:YYY.000.010 XXX:YYY.000.099 Servers, PC with x IP addres
XXX.YYY.000.100 XXX.YYY.000.254 PCs and OnAir consoles using DHCP DHCP range
XXX.YYY.001.001 XXX.YYY.254.254 OnAir consoles with x IP address Up to 254 OnAir consoles with x IP
address according to Studer recom-
mendations
where XXX.YYY is 192.168 in the switch configurations provided by Studer.
For the Livewire network, we recommend to allocate IP addresses according
to the following class–C network scheme, to which all switch configurations
as well as OnAir consoles and Livewire cards provided by Studer comply:
From To Standalone/Integrated
Topology
Routed Topology Comment
XXX.YYY.ZZZ.001 Master Switch Router Gateway
XXX:YYY.ZZZ.002 XXX:YYY.ZZZ.009 additional managed switches
XXX.YYY.ZZZ.010 XXX.YYY.ZZZ.254 Livewire nodes
where XXX.YYY.ZZZ is 10.0.0 in the switch configurations provided by
Studer.
