Studer OnAir 3000 User Manual

OnAir Digital Mixing Consoles
6-134 Conguration
Document generated: 10.10.14
SW V6.0
Function Assignable to: Details
Rel.
in
SW
Key Group Key Unit LED Display Display Module Rotary Unit
CentralRotary1IncDec V3.0 ●
CentralRotary2IncDec V3.0 ●
CentralRotary3IncDec V3.0 ●
CentralRotary4IncDec V3.0 ●
CentralRotaryStart V3.0 ● start button of the stop watch, function without LED
CentralRotaryStop V3.0 ● stop button of the stop watch, function without LED
6.5.37.5 Assignable Channel Strip Functions
Channel strip functions are related to a channel strip. They normally refer to
the input or bus currently routed to this channel strip and allow assigning a
function to a desk element in the Desk_KeyMapping.xml file. Please
note that the color of the key illumination is depending on the module type
(one or two LEDs per key).
Two LEDs per Key (red/yellow) • onallfadermodules
  • ontheeditormodule(OnAir3000)
One LED per Key (yellow) • onrotaryandrotaryassignmodules(OnAir3000)
  • onfaderassignmodules(OnAir3000)
  • onmonitoringmodules
  • ontheXLmodule
  • onthecentralmodule(OnAir2500)
Function Assignable to: Details
Rel.
in
SW
Module with
2 LEDs per key
(red & yellow)
Module with
1 LED per key
(yellow)
Channel On/Off functions
Channel_Mute V1.0 red yellow Inverse function of Channel_On/Off
Channel_Off V1.0 - -
Channel_Off_Yellow V6.0 yellow -
Channel_On V1.0 red yellow
Channel_On/Off V1.0 red yellow
Channel_On/Off_Both V2.0 orange yellow
Channel_On/Off_CMS V2.1
red/orange/
yellow
yellow
Channel_On/Off_Yellow V2.0 yellow -
Channel_On_CMS V2.1
red/orange/
yellow
yellow
PFL & TalkBack functions
PFL_LocMomentary V2.0 yellow/ orange -
if BroadcastPFL mode is set to 1 it lights orange while
the PFL signal is cut
PFL_On/Off V1.0 yellow/ orange -
if BroadcastPFL mode is set to 1 it lights orange while
the PFL signal is cut
PFL_On/Off_momentary V2.0 yellow/ orange -
if BroadcastPFL mode is set to 1 it lights orange while
the PFL signal is cut
PFL_TBMomentaryfromSrc1-4 V2.0
red/orange/
yellow
-
two LEDs: red (TALK), yellow (PFL), orange
(TALK&PFL active)
TBfromSrc1 V1.0 red yellow common used TB function for CR, ST1-3
TBfromSrc2-4 V1.0 red yellow TB source 2-4 only for ST1-3 available
