Studer OnAir 3000 User Manual

OnAir Digital Mixing Consoles
Conguration 6-135
Document generated: 10.10.14
SW V6.0
Function Assignable to: Details
Rel.
in
SW
Module with
2 LEDs per key
(red & yellow)
Module with
1 LED per key
(yellow)
TBfromSrcMO1 V2.0 red yellow momentary function of TBfromSrc1
TBfromSrcMO2-4 V2.0 red yellow momentary function of TBfromSrc2-4
TBPFLfromSrc1 V1.0 red yellow
this function sets TB and PFL simultaneously but indi-
cats only TB stats, see also TBfromSrc1
TBPFLfromSrc2-4 V1.0 red yellow
this function sets TB and PFL simultaneously but indi-
cats only TB stats, see also TBfromSrc2-4
TBPFLfromSrcMO1 V2.0 red yellow momentary function of TBPFLfromSrc1
TBPFLfromSrcMO2-4 V2.0 red yellow momentary function of TBPFLfromSrc2-4
TBREADYfromSrc1 V3.2
red/orange/
yellow
-
two LEDs: red (TALK), yellow (Ready), orange (TALK
& READY active)
TBREADYfromSrc2-4 V3.2
red/orange/
yellow
-
two LEDs: red (TALK), yellow (Ready), orange (TALK
& READY active)
TBREADYfromSrcMO1 V3.2
red/orange/
yellow
- momentary function of TBREADYfromSrc1
TBREADYfromSrcMO2-4 V3.2
red/orange/
yellow
- momentary function of TBREADYfromSrc2-4
Strip select functions
SelectPage_Ass V3.0 red yellow
SelectPage_AUX V3.0 red yellow
SelectPage_DeEs V3.0 red yellow
SelectPage_Dyn V3.0 red yellow
SelectPage_EQ V3.0 red yellow
SelectPage_Input V3.0 red yellow
SelectPage_Ins V3.0 red yellow
SelectPage_NX V3.0 red yellow
StripSelect V1.0 yellow -
StripSelect_LED1 V3.0 red yellow
StripSelect_SplitDesk V2.1 yellow -
this function doesn‘t have any effect on the UserGUI it
is used only for snapshot lter
StripSelect_SplitDesk_LED1 V3.0 red yellow see StripSelect_SplitDesk
StripSelect_SplitDesk_LocalView V4.0 red yellow
see StripSelect_SplitDesk. This function sets the cor-
responding strip in to the LocalView.
Channel Input(Status) functions
ChannelActiv V1.0 orange yellow LED only, condition: Ch_open & Master_assigned
ChannelOnAir V1.0 red yellow LED only, condition: Ch_onMaster & OnAir_relevant
ChannelOnMaster V2.0 red yellow LED only, condition: Ch_activ & Master_fdr_open
ChannelOpen V5.0 red yellow LED only, condition: FaderOpen & ChannelOn
JokerFct V1.0
red/orange/
yellow
yellow/-
Joker functions: TALK, LOC/RDY, PFL/TALK, PFL/LOC
two LEDs: red (TALK, RDY), yellow (PFL)
one LED: yellow (TALK, RDY), dark (PFL)
JokerFctMO V2.0
red/orange/
yellow
yellow/-
momentary only of above Joker functions, PFL/TALK
and PFL/LOC only TALK and LOC respectively can
bee operated
Locate V1.0 - -
Locate/Ready V1.0 yellow -
Ready V1.0 yellow - LED only
Next V1.0 yellow - obsolete, same as NextA
NextA V2.0 yellow -
NextA_LED1 V3.0 red yellow
NextB V2.0 yellow -
