OnAir Digital Mixing Consoles
Conguration  6-39
Document generated: 10.10.14
SW V6.0
6.5.20.2 Patch Groups (OnAir 3000 only)
This page defines the assignment of patch inputs to patch groups that are
displayed in the ROUT - Output page. Selection is done as described in
chapter 6.5.20.1. In addition, each patch group can be given a label.
6.5.20.3 Master Out(put)s
This page defines the order in which the Master Outputs are displayed in the
(horizontal) row on the ROUT - Output page. Selection is done as described
in chapter 6.5.20.1.
The definitions made here are used for output routing (OutRouting, chapter
6.5.20.7) configurations.
