Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
5-132 Operation
Document generated: 10.10.14
SW V6.0
5.10.8 Internal Access Handling
The extensions providing the interface to the user are responsible for checking
the corresponding privileges.
5.10.8.1 User GUI
The user GUI extension checks the privileges on two different levels, i.e.
for pages and for console parameters. For a user having no access right to a
certain page, this page will not open. Access to a console parameter depends
of the current privilege flag setting:
Grant The corresponding button or the black parameter value field above the rotary
encoder is visible and allows controlling this parameter.
Deny The corresponding button or the black parameter value field above the rotary
encoder is not visible, there is no way for controlling this parameter.
Special Cases:
Parameters without Privileges There exist some console parameters without any privileges at all, such as
fader level, channel on/off, PFL). These parameters can be controlled from
the user GUI whenever access to the corresponding page is granted.
Access The Access button on the CHAN - Input page allows requesting access to
the microphone input card’s unique resources. It is visible only if access to
at least one of these parameters is granted.
Insert ON/OFF The privilege for the Insert ON/OFF buttons on the CHAN - FDR/Bus and
the Sum - Master pages is defined in the ROUT::Insert section. Therefore
the Insert ON/OFF button for a certain logical input or master is visible
only if access is granted to the insert currently assigned to that logical input
or master.
Input Routing The input routing (strip assignment) can be controlled from both the CHAN -
Input and the Routing - Input pages. The ROUT::Input - All Parameters
privilege provides access to the strip assignent on both pages.
As a consequence, the CHAN - Input page and the Input Selection button
on this page can be accessed under the following conditions:
  • For logical inputs:
  • TheCHAN - Input page is accessible if either the ROUT::Input - All
Parameters privilege or at least one of the CHAN::Input privileges
are granted.
  • TheInput Selection button on the CHAN - Input page is visible if
the ROUT::Input - All Parameters privilege is granted.
  • For all master buses:
  • TheCHAN - Input page is accessible if the ROUT::Input - All Par-
ameters privilege is granted. Any SUM::... privileges are ignored.
  • TheInput Selection button on the CHAN - Input page is always
visible.
