OnAir 3000 Digital Mixing Console
5-70 Operation
Document generated: 10.10.14
SW V6.0
A time protocol selected with the DIP switches on the (optional) Time Sync
card is displayed on this page as well (also refer to chapter 5.9.1.2).
If you need the screen clock to temporarily display a time different from the
true time, touch the Set Offset button; the offset can be entered with the
rotary encoder below the Offset Time field in a ±12 hours range with a reso-
lution of 30 minutes. An active offset is displayed by a red Offset indicator.
5.3.7.5 Config Page
Important! The system configuration tool (‘Config Tool’) is intended for trained per-
sonnel (such as the system administrator) only; due to the fact that it allows
contradictory settings in some points, care must be applied when using it.
When making configuration changes, it is strongly recommended to backup
the current configuration on an external medium (CF card and/or USB stick)
before, see chapter 6.2; when using a computer with an appropriate slot,
the files on the external medium may then be saved to any backup drive for
additional data safety.
For information on configuration refer to chapter 6.
Slots for external memory media are provided (OnAir 3000: CF card and
USB sockets, OnAir 2500: USB socket). If using the remote configuration
tool, the files can be saved at any desired location.
Backup and Restore may as well be used for copying configurations
between consoles.
Backup If an external memory medium is inserted, this is displayed in the list (e.g.
USBMedia). After touching the Backup button, the screen keyboard pops
up for giving the backup a name. After touching Enter, the configuration files
are copied to the external medium. This takes a few seconds; the Backup
button is highlighted during the transfer.
Restore Select the desired configuration file with the rotary encoder below the Backup
field and touch Restore. After confirmation the configuration data are loaded
into the console’s memory; the Restore button is highlighted during the
transfer. Once finished, the console has to be re-booted by touching Reboot.
